捡拾宽度Uptake width

7.5~9.5m

中间放铺工作宽度Working width in central delivery mode

8.2~9.5m

侧部放铺工作平均宽度Working width in side delivery mode (average incl. window)

8.8m

平均草条宽度  Average window width

侧部放铺:1.0~1.5米   1.00 to 1.50 in side window

中间放铺:大于2.2米  Up to 2.20 in center window

运输尺寸(长x宽x高)Transport length   Transport width   Transport height

7.4x3.0x3.6m

捡拾单元和输送带数量Number of pick-ups and conveyors

2

捡拾单元和输送带驱动Pick-up and conveyor drive

自带液压驱动

Integrated hydraulic unit, belt speed adjustive via variators on the machine

捡拾高度控制Pick-up height control

每个捡拾单元2个滑靴， 多挡位可调

Via 2 skids per pick-up, continuous adjustment by crank

连 接Hitch

2点 一 旋转点 一 2类和3类

2-point-Pivoting lower links-Cat. 2 和 3N

所需最小PTO功率Minimum PTO power requirement approx.

100HP
